⑥ 0-B8 (gray)
--- Apply G126 to surface of cam.
⑦ B7
--- Apply G126 to surface of cam on both sides.
⑧ Align the both hole of 0-B8 and B7.
⑨ B3
⑩ B4
⑪ B5
⑫ B6
⑬ Turn B7 clockwise until the arrow indicated in figure right.
⑭ Clean code plate by solvent and apply G151.
⑮ Latch the lever of G100 while pushing down the sliding plate.
⑬
To Next Page
