77420 - 3/107 -
3. Installing software
[Important] Install below 3 kind of software (The same as 77010:K20D and 77050:K200D)
1. Net Framework Ver2.0 (Common with 77010 and 77050. It is not required if the software is already
installed)
2. VC++2005 SP1 (Common with 77010 and 77050. It is not required if the software is already installed)
3. VB Runtime (Common with other product. It is not required if the VB Runtime is already installed)
* Set Programmed software for 77420 (CD-R) to CD-ROM drive.
①Select [dotnet.exe] from the [NetFramework2.0] folder in CD-ROM then double click icon. Installer will
be started up and follow the instruction on the screen and continue with the installation.
②Select [vcredist_x86.exe] from the [VC++2005 SP1] folder in the CD-ROM then double click icon.
Installer will be started up and follow the instruction on the screen and continue with the installation.
③If [VB Runtime] is not set up to your PC yet, select [setup.exe] from the [vb6run_cs_xxx] folder in
CD-ROM then double click icon. Installer will be started up and follow the instruction on the screen and
continue with the installation. (Refer to the service manual for 76700 for details)
4. Calibration of light source for Digital adjustment
[Important] Execute Calibration of light source before 77420 Digital adjustments.
When replaced the program software, replaced light source or replaced AE master lens, it is required
calibration. (Refer to the service manual for 76830 K10D for calibration procedure)
[Required equipment]
K10D Master body for calibration (HOYA Corporation will rend the master body. Please contact with us)
Digital adjustment software for 77420 (M-test)
Computer (Windows Xp, support USB), Light source (Example: LB3300, A light source)
Master lens for 76180 (D20 or D20-01), and F8 set ring
*Use the same master lens as the ID number printed on CD-ROM to adjust it accurately.
USB cable, AC adaptor for 76830, Dark curtain, Color temperature tester (for calibrate light source),
LV meter (for check LV value)
4-1. setting for computer
Complete the [2. Setting for computer] of [PREPARTAION]. (Use software for Digital adjustments)
4-2. Calibration of light source
①Before calibration, turn ON the light source and leave 30 minutes for stabilizing light source.
②Calibrate Color temperature and Brightness by using color meter and LV checker as shown below table.
Light
source
Brightness Color
temperature
LV12 LV12.00Ev ±0.50 2,856K ±30
*Calibrate with using the master body according to the following procedure.
To Next Page
