77420 - 4/107 -

4-3. Setting for Master body and Master lens

①Set the mode dial to [M].

②Set the focus mode lever to [MF].

③Set SR function [OFF].

④Attach the master lens and F8 set ring to the body.

⑤Set the master lens aperture to [F8 position]

4-4. Procedure for calibration

①Connect the AC adaptor to the master body.

②Connect to PC with USB cable.

③Turn ON the power and confirm that the camera is recognized by PC.

④Set the light source to [LV12].

Surely set the camera and lens toward center of light window and cover the whole camera and light

window by using a dark curtain

⑤Double crick the adjusting software[K-r_ SLR_MTest.exe] in [K-r_ MTest] folder to start-up.

⑥On first screen, select [Adjust All] and input the lens ID number correctly then click [Enter].

⑦When below screen is displayed, click around the title in blue frame to change calibration mode.
