Pentax OPTIO M10 User Manual

23
1
Getting Started
Use of the AC adapter kit K-AC51 (optional) with a household power
supply is recommended if you intend to use the camera for a long time
or connect it to a computer.
(The AC adapter kit K-AC51 includes AC adapter D-AC5, DC coupler
D-DC51, and AC plug cord D-CO2.)
1 Connect the DC terminal of the AC adapter to the DC
input terminal of the DC coupler.
2 Make sure that the camera is turned off and open the
battery/card cover.
Pull the battery/card cover in the direction of 1 and flip the cover open
in the direction of 2.
3 Insert the DC coupler into the battery compartment,
making sure the (+) and (–) on the coupler match the (+)
and (–) on the battery compartment.
4 Open the DC coupler cable cover, pass the DC coupler
cable through the opening, and close the battery/card
cover.
Slide the battery/card cover in the opposite direction of 1. Slide the
battery/card cover all the way in to make sure it is securely closed.
5 Connect the AC plug cord to the AC adapter.
6 Plug the AC plug cord into the power outlet.
Using the AC Adapter with a Household Power Supply
4
AC adapter
AC plug cord
DC terminal
2
3
1
5
6
DC input terminal
DC coupler
DC coupler cable cover
DC coupler cable

Pentax OPTIO M10 Specifications

General

Megapixel	6 MP
Camera type	Compact camera
Sensor type	CCD
Image sensor size	1/2.5 \
Digital zoom	4 x
Optical zoom	3 x
Color depth	12 bit
Digital SLR	No
Built-in flash	Yes
Dimensions (WxDxH)	89 x 24.5 x 59.5 mm
Maximum video resolution	320 x 240 pixels
Display diagonal	2.5 \
Display resolution (numeric)	115000 pixels
Number of batteries supported	2
Product color	Silver
Compatible memory cards	sd

Weight and Dimensions

Depth	24.5 mm
Width	89 mm
Height	59.5 mm
Weight	165 g
