Pepperl+Fuchs KCD2-SCS-Ex2.SP System Manual

K-System – Isolated Barriers
Product Specifications
DOCT-0187Y 2023-12
17
2.6 Operating Elements
Many devices of the K-System can be adapted to different applications.
Depending on the device different operating elements are available for this configuration.
These operating elements are:
DIP switches
Via DIP switches you can configure the basic functions of the device.
Figure 2.16
Rotary switches
Via rotary switches you can configure the basic functions of the device.
Figure 2.17
Potentiometers
Via potentiometers you can configure the calibration of input and output characteristics.
Figure 2.18
1 DIP switch
1 Rotary switch
1 Potentiometer
S2
S1
S3
III
1
S2
1
2
3
0
4
5
9
8
7
6
1
SPAN
ZERO
1
