Pepperl+Fuchs WCS Series User Manual

2020-01
52
WCS* Read Head Position Encoding System
EtherNet/IP Interface (LS5xx*)
Faults: error value (ID 102)
Data for attribute 102
A binary encoded value in attribute 100 means that the corresponding fault is active.
Size Type Content
1 byte consistent Input data 8 bit fault data
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 1 ERR7 ERR6 ERR5 ERR4 ERR3 ERR2 ERR1 ERR0
Value
Content
Function
Byte 1
Status
0 Error 0 -
1 Error 1 Current position cannot be determined.
2 Error 2 Current position cannot be determined.
3 Error 3 Fault in the RAM working memory.
4 Error 4 Fault in the EPROM memory or in the decoder.
5 Error 5 Fault in the ROM memory.
6 Error 6 -
7 Error 7 -
