2020-01
74
WCS* Read Head Position Encoding System
Appendix
SSI (LS3xx*)
CANopen (LS4xx*)
Cable Description
Pre-configured cable
V19-G-2M-PUR-ABG M12 single-ended female cordset, eight-pin, straight, 2 m PUR cable,
shielded,
V19-G-5M-PUR-ABG M12 single-ended female cordset, eight-pin, straight, 5 m PUR cable,
shielded,
V19-G-10M-PUR-
ABG
M12 single-ended female cordset, eight-pin, straight, 10 m PUR
cable, shielded,
V19-G-2M-PVC-TP Female cordset, M12, eight-pin, shielded, 2 m PVC cable
Shielded twisted pair
V19-G-5M-PVC-TP Female cordset, M12, eight-pin, shielded, 5 m PVC cable
Shielded twisted pair
V19-G-10M-PVC-TP Female cordset, M12, eight-pin, shielded, 10 m PVC cable
Shielded twisted pair
Configurable female cordset and meter goods
V19-G-ABG-PG9 Eight-pin single-ended female cordset, field attachable, shielded
V19-G-ABG-PG9-FE Eight-pin single-ended female cordset, field attachable, shielded with
grounding terminal
WCS-DCS
Available by the meter, six-pin data cable + shield, 0.14 mm
2
3 x 2 twisted wire pair
WCS-DCF
Available by the meter, six-pin data cable + shield, 0.25 mm
2
3 x 2 twisted wire pair, suitable for drag chains
Cable Description
Pre-configured cable
V15-G-2M-PUR-CAN CANopen bus cable, M12, 2 m PUR cable, five-pin
V15-G-2M-PUR-CAN-
V15-G
CANopen bus cable, M12 to M12, 2 m PUR cable, five-pin
V15-G-5M-PUR-CAN-
V15-G
CANopen bus cable, M12 to M12, 5 m PUR cable, five-pin
V15-G-10M-PUR-
CAN-V15-G
CANopen bus cable, M12 to M12, 10 m PUR cable, five-pin
Configurable female cordset and meter goods
V15-G-ABG-PG9-FE Female connector, M12, five-pin, shielded, field attachable
WCS-DCS
Available by the meter, six-pin data cable + shield, 0.14 mm
2
3 x 2 twisted wire pair
WCS-DCF
Available by the meter, six-pin data cable + shield, 0.25 mm
2
3 x 2 twisted wire pair, suitable for drag chains
