WCS* Read Head Position Encoding System
Appendix
2020-01
75
EtherNet/IP (LS5xx*) & PROFINET (LS6xx*)
Cable Description
Hybrid cable with common data line and supply voltage
V19SY-G-BK2M-
PUR-ABG
Single-ended male cordset, M12, 8-pin, Y coding, 2 m PUR cable,
shielded
V19SY-G-BK5M-
PUR-ABG
Single-ended male cordset, M12, 8-pin, Y coding, 5 m PUR cable,
shielded
V19SY-G-BK10M-
PUR-ABG
Single-ended male cordset, M12, 8-pin, Y coding, 10 m PUR cable,
shielded
Y-splitter and cable (data cable and supply voltage separated)
V19SY-Y-V1D/V1S Y-splitter, M12 plug Y-coded to A-coded M12 plug/D-coded socket
V1SD-G-*M-PUR-
ABG-V45-G
1
1. This cable type is available in various lengths 2 ... 45 m.
Cordset, M12 to four-pin RJ-45 PUR cable, CAT5e,
in conjunction with Y-plug (data cable)
V1-G-BK10M-PUR-U Single-ended female cordset, M12, four pins, PUR cable,
in conjunction with Y-plug (supply voltage)
