2.7 MAX Transit (CAT-18)

2.7

.2 LED Indicators

The statuses indicated by the front panel LEDs are as follows:

Status Indicators

Status

OFF System initializing

Red Booting up or busy

Blinking red Boot up error

Green Ready
