2.25 MAX BR1 ENT
2.25.1 Panel Appearance
2.25.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
Status Indicators
Status
OFF System initializing
Red Booting up or busy
Blinking red Boot up error
Green Ready
Cellular Indicators
Cellular
OFF Disabled or no SIM card inserted
Blinking slowly Connecting to network(s)
Green Connected to network(s)
LAN and Ethernet WAN Ports
Green LED ON 10 / 100 / 1000 Mbps
Orange LED
Blinking Data is transferring
OFF No data is being transferred or port is not connected
Port Type Auto MDI/MDI-X ports
