PERFECTPASS StarGazer - Jump Settings Parameters

13
Example: If a boat was not slowing quickly enough in the 2
nd
segment, you would lower the value.
Typical values 2008 Promo Boats with DBW PerfectPass
5.7L 6.0L
x8u 85 650
x8d 275 275
One Magnet Timing - In the background settings, you can switch from multi-magnet to one-ball
timing. If you select one- ball in Jump or Slalom, it carries over to the other mode.
Jump Settings
New Times (Faster Second Segment)
Examples for when towing jumpers over 120 Feet.
Jump Settings
S2%
S2 RTB
CT
Ski Nautique
Faster 60 – 120
Faster 10
190
MasterCraft
Faster 60 – 120
Faster 10
190
Malibu
Faster 60 – 120
Slower 5
190
Others
Faster 60 – 120
Slower 5
190
Important Tip: Once engaged, the throttle handle should be pushed forward to provide the system
with room to throttle up. For long distance jumpers, it should be moved to full open.
