MAN-0012 Rev. I Page | 39
1. Flake out the canopy until
all seven T seams (where the
non- loaded ribs meet the top
skins) are straight from
leading edge to trailing edge.
2. Be sure the canopy is
flaked and straight. Grasp the
seven T seams at the leading
edge in your left hand. Grasp
the seven T seams directly
above the A lines with your
right hand. Pull tension
against the rig to be sure the
A lines are straight, and then
fold the leading edge back
under the canopy so the A-
line path is on the far left as
you look from canopy top
toward the rig.
3. Hold down the canopy at
the A-line path, find the
seven T seams directly above
the B-line path and fold to the
left, placing the B lines on the
top of the A lines.
