Performance Tool W1640 User Manual

6
5
9
15
16
17
18
12
19
13
16
15
11
3
4
2
1
30
29
27 28
33
31
32
30
29
20
25
26
14
Ram Assembly
(See figure 6)
22
10
7
8
24
23
21
17
01 Nut M12 2 02 Washer 12 2 03 Front Wheel 2 04 Axle Bushing 2 05
Snap Ring "C" 13
2
06 Saddle Shaft 1 07 Saddl Bracket 1 08
Snap Ring "C" 13
1
09 Saddle 1 10 Saddle Pin 1 11 Front Wheel Axle 1
12 Frame Unit - Left 1 13 Middle Shaft 1 14 Lift Arm Axle 1 15 Long Linker 2 16
Snap Ring "C" 10
2
17 Lift Arm 1 18
Snap Ring "C" 19
2
19 Shaft 1 20 Piston Rod Shaft 1 21 Carry Handle 1 22 Inspection Plate 1
23 Ram 1 24 Handle Cover 1 25 Handle 1 26 Spring 1 27 Nut M8 4 28 Washer 8 4 29 Washer 12 6 30 Nut M12 4 31 Ball Bracket 2 32 Caster Bracket 2 33 Frame Unit - Right 1
Parts List
REPLACEMENT PARTS LIST Figure 4
# Description Qty. # Description Qty. # Description Qty.

Performance Tool W1640 Specifications

General

Brand	Performance Tool
Model	W1640
Category	Jacks
Language	English
