Performance Tool W1643 User Manual

7
1 Release Valve 1
2 Rectangle seal ring 3
3 Steel Ball 1
4 Base 1
5 Pin 4
6 Pumping Handles 2
7 Pin Shaft 5
8 Connecting Bar 1
9 Handle Sleeve 1
10 Steel Ball 2
11 Washer 1
12 O-Ring 1
13 Shield Ring 1
14 Pump Core 1
15 Pump Body 1
16 Filter screen 1
17 Washer 1
18 Bowl Washer 1
19 Piston 1
20 Adjustable Top Screw 1
21 Washer 1
22 Hydraulic Cylinder 1
23 Seal Ring 1
24 Oil Tank 1
25 Oil Plug 1
26 Seal Ring 1
27 O-Ring 1
28 Top Nut 1
29 Carry Handle
# Description Quantity
REPLACEMENT PARTS LIST
