11
REPLACEMENT PARTS LIST
SPREADER WEDGE
S01 Pin 1
S02 Circlip 1
S03 Moveable Jaw 1
S04 Spring 1
S05 Fixed Jaw 1
S06 Piston 1
S07 Cup Seal 1
S08 O-ring 1
S09 End Cap 1
S10 Coupling Ring 1
S11 Coupling Bolt 1
P11 O-Ring 1
S12 Dust Cap 1
# Description Qty # Description Qty
# Description Qty
R01 Cover 1
R02 Circlip 1
R03 Piston Rod 1
R04 Circlip 1
R05 Bushing 1
R06 Nylon Ring 1
R07 Sealing Ring 1
R08 Circlip 1
R09 Nut 1
R10 Spring 1
R11 Screw 1
R12 Protection Cup 1
R13 Ring 1
R14 Cylinder 1
R15 Screw 1
S10 Coupling Ring 1
S11 Coupling Ring 1
P11 O-Ring 1
S13 Dust Cap 1
RAM
