6
2. Plug 120V AC Adapter into household
outlet and into side of battery charger.
The Red indicator light will come “ON”.
3. Insert battery pack into battery charger.
The Green indicator light will come “ON”
indicating that battery is being charged.
4. After 3 - 5 hours of charging, remove the
battery pack from charger and reat-
tach battery pack onto Cordless Impact
Wrench, making certain latches fasten
securely. Cordless Impact Wrench will
not operate properly if the battery pack
is not seated properly.
NOTICE Continuous use of your tool
causes the battery pack to become hot.
Let a hot battery pack cool down for ap-
proximately 30 minutes before attempt-
ing to recharge.
Battery Pack
Battery Charger
120V AC Adapter
INSTALLING ACCESSORIES
CAUTION
When removing the socket or
bit from the tool, avoid contact with skin
and use proper protective gloves when
grasping the socket, bit or accessory.
Accessories may be hot after prolonged
use.
1. To installing a socket, press the socket
on until it locks securely in place.
2. To remove a socket, pull the socket
while slightly rotating.
OPERATING THE IMPACT WRENCH
WARNING
Never tape the trigger switch
down to provide continuous high speed.
The tool may fail under such conditions
causing fire or personal injury.
VARIABLE SPEED TRIGGER SWITCH:
• The speed of the Cordless Impact
Wrench depends on the amount of
pressure you put on the trigger.
• The more pressure you apply, the faster
the Cordless Impact Wrench will go.
• Release the pressure and the Cordless
Impact Wrench will slow down.
OPERATION
WARNING Be aware that this tool is always in an operating condition because it does
not have to be plugged into an electrical outlet. Always lock the Trigger Switch and
remove the battery pack before changing accessories.
Figure 2
BATTERY PACK USAGE AND CHARGING OPERATIONS
Trigger
Switch
