16
15 Big gear 1 57 Stator 1
16 Circlip for shaft D9 2 58 Deep groove ball bearing 608-2Z 1
17 Circlip for shaft D8 1 59 Rotor 1
18 Pinion 1 60 Socket terminal 2.8X0.8 2
19 Separation sleeve 1 61 Self-tapping screw ST2.9X10 2
20 Circlip for hole D20 2 62 Lower carbon brush holder 1
21 Deep groove ball bearing 699 1 63 Carbon brush 2
22 Pipe joint C 1 64 Deep groove ball bearing 606.2Z 1
23 Bellows 1 65 Bearing sleeve 1
24 Pipe joint D 1 66 Upper carbon brush holder 1
25 Self-tapping screw ST4.2X14 6 67 Self-tapping screw ST4.2X16 9
26 Gear box 1 68 Right housing 1
27 Dust cover 2 69 Right label 1
28 Spindle(120V) 1 70 Power cord sleeve 1
29 Fixed guard 1 71 Hex key 5 1
30 Pan Head Philips screw(with
washer)
2 72 Power cord 1
31 Cross-shaped screw M4X12 1 73 Circlip for shaft D10 2
32 Rubber block 1 74 Depth lever 2
33 Screw for rubber block M5 1 75 Locking lever 2
34 Moving guard 1 76 Washer 1
35 Baffle ring 1 77 Hexagon socket head cap screws
M6X12
1
36 Inner flange 1 78 Edge guide locking spring 1
37 TCT blade 1 79 Base plate 1
38 Blade fixed screw 1 80 Cylindrical spring pin D6X35 1
39 Outer flange(120V) 1 81 Parallel guide 1
40 Self-tapping screw ST4.2X12 1 82 Power cord clamp 1
41 Moving guard lever 1 83 Wires connecting blocks 1
42 Left label 1
