15
CAUTION
Certain cleaning agents and solvents may damage plastic parts. Some of these
are: gasoline, carbon tetrachloride, chlorinated cleaning solvents, ammonia and
household detergents that contain ammonia.
WARNING
If any of the following events occur during normal operation, the power supply
should be shut off at once and tool thoroughly inspected by a qualified person and
repaired if necessary:
- The rotating parts get stuck or speed drops abnormally low.
- The tool shakes abnormally accompanied by some unusual noise.
- The motor housing gets abnormally hot.
- Heavy sparks occur around the motor area
ACCESSORIES
Hex key
......................................................................................................... 1 pc
Parallel Guide
................................................................................................ 1 pc
Instruction Manual
......................................................................................... 1 pc
4-1/2” TCT Blade
........................................................................................... 1 pc
Dust pipe…
................................................................................................... 1 pc
PARTS LIST
Nr. Description Qty Nr. Description Qty
1 PanHeadPhilips screw M4X14
(with washer)
5 43 Left housing 1
2 Spindle lock cap 1 44 Screw for tension spring 1
3 Spring for spindle lock 1 45 Spring washer 1
4 Gear box cover 1 46 Spindle lock cap 1
5 Circlip 1 47 Tension spring 1
6 Cup head square neck bolts
M6X26
2 48 Trigger 1
7 Deep groove ball bearing 698 1 49 Spindle lock spring 2
8 Big spiral bevel gear 1 50 Socket terminal4.8X0.8 2
9 Steel ball S
φ
3 3 51 Switch 1
10 Primary gear shaft 1 52 Gear for connecting rod 1
11 Deep groove ball bearing 607-2Z 4 53 Deep groove ball bearing 609.2Z 1
12 Circlip for hole D19 2 54 Circlip for hole D24 1
13 Washer(7.1X
φ
13X0.5) 1 55 O ring 1
14 Intermediate shaft 1 56 Connecting sleeve 1
