Performax 90235 User Manual

Exploded view & parts list (continued)
Item# Description Qty Item# Description Qty
1A Motor Assembly (from 1~55) 1 46 Gear Box 1
1 Power 1 47 Bearing, 6000 1
2 Power Cord Bush 1 48 C-ring, GB894.1-86 22 1
3 Screw, GB818-85 M5x20 4 49 Big Gear 1
4 Carry Handle (L), PA6-GF30 1 50 Sleeve 1
5 Spring Washer, GB93-87 5 22 51 Key, 5x12 1
6 Carry Handle (R), PA6-GF30 1 52 Shaft 1
7 Screw, GB845-85 ST4x14 4 53 Bearing, 6004 1
8 Flat Washer, GB93-87 5 25 54 C-ring, GB894.1-86 42 1
9 Screw, GB819-85 ST5x16 4 55 Gear Box Cover 1
10 Screw, GB818-85 M5x8 2 56 In Flange 1
11 Left Side Board 1 57 Blade Sleeve 1
12 Switch Trigger 1 58 Screw, GB818-85 M4x10 3
13 Nut, GB6170-86 M6 3 59 Spring Washer, 1GB93-87 4 7
14 Switch, HY18 1 60 Flat Washer, GB93-85 4 5
15 D-handle (up), PA6-GF30 1 61 Laser Cover, PA6-GF30 1
16 Circuit Breaker 1 62 Laser Switch 1
17 Right Side Board 1 63 Screw, GB845-85 ST3x10 6
18 Screw, GB845-85 ST4x16 6 64 Battery Cover, PA6-GF30 1
19 Flat Washer, GB93-87 6 3 65 Battery Spring 3 1
20 Screw, GB818-85 M6x45 3 66 Battery 2
21 Strain Relief 1 67 Screw, GB818-85 M4x12 2
22 Wire Nip 1 68 Battery Spring 1 1
23 Screw, GB845-85 ST4x12 1 69 Battery Box 1
24 D-handle (down) 1 70 Screw, GB818-95 M5x25 2
25 Screw, GB845-85 ST5x16 4 71 Laser Base 1
26 Brush Cap 2 72 Battery Spring 2 1
27 Brush Holder 2 73 Laser 1
28 Spring 2 74 Laser Press Board 1
29 Carbon Brush 2 75 Laser Jointer 1
30 Screw, GB77-85 M5x6 2 76 Jointer Baser 1
31 Arm 1 77 Laser Guard 1
32 Wire Bush 1 78 Blade 1
33 Gear Washer, GB862.2-87 4 1 79 Out Flange 1
34 Screw, GB818-85 M4x8 1 80 Thickness Washer 1
35 Stator Assembly 1 81 Blade Screw 1
36 Flat Washer, GB95-85 5 2 82 Screw, GB818-85 M5x60 4
37 Spring Washer, GB93-87 5 2 83 Up Guard 1
38 Screw, GB818-85 M5x80 2 84 Guard Stop 1
39 Bearing 1 85 Locknut, GB/T889.1-2000 M8 1
40 Rotor Assembly 1 86 Locknut, GB/T889.1-2000 M5 1
41 Fan Bearing 1 87 Low Guard 1
42 Fan Ring, PA6-GF30 1 88 Guide Wheel 1
43 Lock Pin 1 89 Big Washer 1
44 Lock Pin Knob, PA6-GF30 1 90 Hinge 1
45 Spring, 65Mn 1 91 Spring, 65Mn 1
16
