PerkinElmer Lambda 465 Assembly/Installation Instructions

09931295C
16
4. Place the magnetic stirrer head on the stirrer mount of the 8 cell water jacketed cell changer.
Figure 33 Placing the magnetic stirrer head on the stirrer mount
5. Fix the stirrer mount to the 8 cell water jacketed cell changer and tighten the screw using the M4
wrench.
Figure 34 Fixing the stirrer mount
Connect to the Water Jacketed Automatic Referencing Stage
1. Connect the plug of the power cable with the power input socket of the control unit.
Figure 35 Connecting the plug of the power cable
