PerkinElmer TGA 4000 User Manual (English)

Questions and Answers:

B
Brent WilliamsAug 18, 2025
What to do if the PerkinElmer Measuring Instruments furnace still contains a sample while trying to load a new one?
- D
  djohnsonAug 18, 2025
  If the furnace still contains a sample when trying to load a new one, it could be due to several reasons. Check if the gripper fingers are bent, and replace the gripper assembly if necessary. Adjust the baseplate. Recalibrate the AS 6000. Also, reset the parent instrument and set up the link again, especially if the AS 6000 run was interrupted after placing a sample in the furnace and restarting.
J
Julie GeorgeAug 20, 2025
What to do if there is no +12 V power supply available for the stepper motor power supply in PerkinElmer Measuring Instruments?
- D
  daniel87Aug 20, 2025
  If there is no +12 V power supply available, it may be due to an overload condition in the switched power supplies. Check the stepper motor wires. If the issue persists, replace the AS 6000 assembly or the controller PCB.
B
Breanna GreeneAug 22, 2025
What to do if the PerkinElmer Measuring Instruments zero position is not detected?
- K
  Kelly LoweAug 23, 2025
  If the zero position is not detected, it might be due to direct sunlight interfering with the light switches or a displaced gripper assembly. Avoid placing the instrument in direct sunlight and align the gripper assembly.
J
Jamie TaylorAug 26, 2025
What to do if PerkinElmer Measuring Instruments has no link between TGA and AS 6000 via I2C?
- J
  Jackie LeeAug 26, 2025
  If there is no link between the TGA and AS 6000 via I2C, the I2C connection cable might be defective. Replace the I2C cable.
A
allenjesusAug 27, 2025
What to do if the PerkinElmer Measuring Instruments horizontal stepper motor is blocked?
- A
  alexandercruzAug 28, 2025
  If the horizontal stepper motor is blocked, check for blocked gear wheels or any external object obstructing it. Inspect the gear wheels and remove any external object.
K
Kevin MoraAug 30, 2025
What to do if the PerkinElmer Measuring Instruments vertical stepper motor is blocked?
- D
  Dr. Stephanie LittleAug 30, 2025
  If the vertical stepper motor is blocked, it could be due to incorrect calibration, blocked gear wheels, an external object, or a misplaced inner lid of the DSC. Recalibrate the AS 6000, check the gear wheels, remove any external objects, and replace the DSC inner lid.
Q
qcolonSep 2, 2025
What to do if PerkinElmer Measuring Instruments light switches are not functioning?
- M
  Marisa FosterSep 2, 2025
  If the light switches are not functioning or are blocked when the gripper is in a raised position, it could be due to a blocked light switch, a faulty light switch, or a problem with the AS 6000 cable. Remove any object blocking the light switch, replace the AS 6000 mechanics, and check or replace the AS 6000 connection board.
L
Lori OsborneSep 4, 2025
What to do if PerkinElmer Measuring Instruments microswitch is activated when gripper is NOT in reset state?
- C
  clarencejonesSep 4, 2025
  If the microswitch is activated when the gripper is not in the reset state, it could be due to a faulty microswitch, incorrect microswitch wiring, or a problem with the AS 6000 cable. Replace the gripper assembly, check the microswitch wiring, and check or replace the AS 6000 connection board.
R
Robert MillsSep 7, 2025
Why does the PerkinElmer Measuring Instruments gripper contain no sample when entering furnace?
- J
  jamesjeremySep 7, 2025
  If the gripper contains no sample when entering the furnace, it is because there was no sample pan at the reserved position on the sample tray. Place a sample on position 0 of the sample tray.
I
ibrownSep 9, 2025
What to do if the PerkinElmer Measuring Instruments gripper still holds sample while moving OUT of furnace?
- W
  williamsmelissaSep 9, 2025
  If the gripper still holds the sample while moving out of the furnace, it is likely because the sample sticks to the gripper fingers. Clean the gripper tips and use clean sample pans.

PerkinElmer TGA 4000 Specifications

General

Brand	PerkinElmer
Model	TGA 4000
Category	Measuring Instruments
Language	English

Summary

Introduction

Safety and Regulatory Information

Symbols Used in Online Help

Explains symbols in Pyris help for safe operation.

Notes, Cautions and Warnings

Defines standard formats for notes, cautions, and warnings.

Symbols Used on the Instruments

Illustrates graphic symbols on instruments for safety.

Electrical Warnings

Details electrical connection and safety warnings for the instrument.

Electromagnetic Compatibility (EMC)

Outlines EMC standards and compliance for different regions.

Electrical Safety

Conforms to safety requirements for electrical equipment and directives.

Pollution Degree 2

Specifies safe operation in environments with nonconductive foreign matter.

WEEE Instructions for PerkinElmer Products

Provides guidance on disposal of electrical and electronic equipment.

Prepare the Laboratory

Electrical Requirements

Details power source, line voltage, and instrument power needs for setup.

Environmental Requirements

Lists necessary laboratory conditions: clean area, stable power, humidity, temperature.

Purge Gas and Pneumatic Supply Requirements

Specifies requirements for purge gas purity and connection.

Space Requirements

Details physical space, altitude, and installation overvoltage category.

Install Multiple Analyzers

Connecting Multiple Analyzers via USB

Explains using USB multiport (EdgePort) for connecting multiple instruments.

Install a TGA 4000

Safety Precautions for the TGA 4000

Lists essential safety guidelines for operating the TGA 4000.

Important Specifications

Provides key technical details like power, voltage, fuses, and dimensions.

Decontamination and Cleaning

Covers procedures for decontaminating and cleaning the instrument.

TGA 4000 Warning Labels

Details warning labels on the upper ring around the furnace.

Warning Labels on the Back of the TGA 4000

Illustrates and explains warning labels on the rear panel.

Unpack the TGA 4000

Step-by-step instructions for safely removing the TGA 4000 from packaging.

Parts Included

Lists components found in the Spares and Accessories Kit.

Set Up the TGA 4000 System Components

Guides on selecting voltage, installing gases, cooling, and leveling.

Connect the Purge Gas Supply to the TGA 4000

Details connecting purge gas inlets for system and sample.

Connect the Purge Gas and System Purge Gas Lines to the TGA 4000

Connects sample and system purge gas lines.

Connect the Cooling Device to the TGA 4000

Instructions for connecting the integrated cooling system or external chiller.

Connecting to tap water

Procedure for connecting the instrument to a tap water cooling supply.

Level the TGA 4000

Steps to ensure the analyzer is properly leveled on the bench.

Connect the TGA 4000 System Components

Guide for connecting the TGA 4000 to the computer and printer.

Configure the TGA 4000

Steps to configure the TGA 4000 within the Pyris software.

Starting the Pyris Manager

Instructions on how to start Pyris Manager and the control panel.

Calibrate the TGA 4000

Details procedures for furnace, temperature, and weight calibration.

Weight Calibration

Specific steps for performing the weight calibration of the TGA 4000.

TGA 4000 Hardware

TGA 4000 Thermogravimetric Analyzer

Overview of the TGA 4000's features, applications, and benefits.

Features of the TGA 4000

Describes the balance, furnace, cooling system, and autosampler compatibility.

Heating

Explains temperature range and maximum heating rates based on supply voltage.

Sample Handling

Discusses sample preparation, pans, and atmosphere control for TGA analysis.

Loading the Sample into the TGA 4000

Step-by-step guide for loading samples into the furnace.

Calibration

Explains when recalibration of furnace, temperature, or weight is necessary.

Maintenance

Outlines routine maintenance tasks, including cleaning procedures.

Changing the Sample Thermocouple

Procedure for replacing the sample thermocouple.

TGA 4000 Part Numbers

Lists part numbers for supplies, accessories, and replacement parts.

Miscellaneous Part Numbers

Lists miscellaneous part numbers for tubing, cables, and fuses.

AS 6000 Autosampler

Introduces the AS 6000 autosampler accessory for automation.

Safety Precautions for the AS 6000

Lists safety precautions specific to the AS 6000 autosampler.

How the AS 6000 Autosampler Works

Explains operation and automation of the AS 6000 with Pyris software.

Autosampler Work Cycle

Describes the typical sequence of operations performed by the autosampler.

Reduced Time Cycle

Details a faster cycle option by eliminating lid replacement steps.

AS 6000 Autosampler Gripper Alignment

Procedure for aligning the autosampler's gripper if sample handling is incorrect.

AS 6000 Sample Handling

Covers sample preparation, loading, and taring crucibles for the autosampler.

Running a Play List with the AS 6000

Guide on creating and running sample analysis sequences using Pyris Player.

Troubleshooting

Lists common AS 6000 error messages, causes, and corrective actions.

Error Messages from the TGA 4000

Specific error messages related to AS 6000 interaction with TGA 4000.

AS 6000 Autosampler Maintenance

Covers cleaning and decontamination procedures for the autosampler.

Replace the Sample Thermocouple in a TGA 4000, Pyris 6 TGA or STA 6000 with AS 6000 Autosampler

Detailed steps for replacing the sample thermocouple with autosampler attached.
