DOC, DPF, and SCR Serial Plate
Illustration 28 g03713367
Typical example
The plate (1) is installed after the DPF.
Record all the information on the serial plate for your
aftertreatment system. The information will be
required by your Perkins distributors.
Pump Electronic Unit
Illustration 29 g03700583
The serial plate (1) for the pump electronic unit is
installed beside the diesel exhaust fluid filter.
i05673571
Emissions Certification Film
The label for the emission is installed on the front
gear cover.
Note: A second emission label will be supplied with
the engine. If necessary, the second emission label
will be installed on the application by the original
equipment manufacturer.
SEBU9063-07
33
Product Information Section
Emissions Certification Film
