DOC and SCR
Illustration 31 g03417158
Typical example
There are two sizes of CEM that can be installed. A
high powered CEM and a low powered CEM. The
approximate weight of the high powered CEM is
47 kg (104 lb), the approximate weight of the low
powered CEM is 42 kg (93 lb).
Two suitable double looped slings are required to lift
the CEM. Also, a suitable hoist will be required to
remove and install the assembly.
The slings must be attached to the CEM as shown in
illustration 31 .
Ensure that the slings only contact the body of the
CEM. A test lift may be required to achieve the
correct balance of the assembly.
36
SEBU9063-07
Operation Section
Aftertreatment Systems
