Illustration 40 g03420017
Typical example
(12) Wastegate Regulator
(13) Inlet Pressure Sensor for the NOx
Reduction System (NRS)
(14) Control Valve for the NRS
(15) Temperature Sensor for the NRS
(16) Differential Pressure Sensor for the
NRS
SEBU9063-07
55
Operation Section
Sensors and Electrical Components
