Product Identification
Information
i06091255
Plate Locations and Film
Locations
Illustration 20 g02446959
(1) Serial number plate
(2) Information plate
The engine serial number plate is located on the right
side of the engine block, toward the back.
Illustration 21 g01403841
Serial number plate
The following information is stamped on the serial
number plate: engine serial number, engine model
and arrangement number.
The engine information plate is located on top of the
valve cover near the middle of the engine.
The following information is on the information plate:
engine serial number, engine model, engine
arrangement number, maximum altitude of the
engine that is necessary to achieve the rated power,
horsepower, high idle, full load rpm, fuel settings and
other information
The Clean Emission Module (CEM) identification
plate is located on the bracket assembly on the CEM.
24
SEBU9071-01
Product Information Section
Product Identification Information
