Perlesmith PSCM2 - Hardware Details; Hardware for Attaching Wall Plate to Wall; Hardware for Attaching TV Bracket to TV

M6x10mm M622x6.4x2
M6X55mm
M6X60mm
Supplied Hardware
Hardware for Attaching TV Bracket to TV
Washers
M8
x4
A2
Spacers
L10mm
x8
Philips Screws
M6 x 15mm
M6 x 45mm
x4x4
D1 D2
Philips Screws
M8 x 15mm
M8 x 45mm
x4
x4
E1
E2
B2
Spacers
L5mm
x8
x2
x4
x7 x2 x1x2
C
Washers
M6
x11
B1
Hardware for Attaching Wall Plate to Wall
CAUTION!
M8X65
Lag Bolts
x4
A3
x4
A1
Wall
Anchor
Philips Screws
M4 x 30mm
F
x4
These anchors
are for concrete
or brick walls
ONLY. DO NOT
use them in
drywall or wood
studs.
a
f
b c d e
2
Plastic Washer
16x6.4x1.5
x4
h
M6 Bolt
x1
g
Allen Wrench
5x5
