Perlesmith PSCM2 - STEP 2 B Solid Concrete or Concrete Block Option

STEP 2B Solid Concrete or Concrete Block Option
Avoid potential personal injury or property damage! All lag bolts [A1]
MUST BE firmly tightened to prevent unwanted movement of the U
Bracket [2].
WARNING:
Wall
Anchor
A3
WARNING:
Ensure the U Bracket [2] is securely fastened to the
ceiling before continuing on to the next step.
WARNING:
● Anything covering the ceiling must not exceed 5/8 in. (16 mm)
● Mount the U Bracket [2] directly onto the concrete surface
● Minimum solid concrete thickness: 203 mm (8 in.)
● Minimum concrete block size: 203 x 203 x 406 mm (8 x 8 x 16 in.)
5
25/64 in.(10mm)
Concrete Drill
[7]
