Perlesmith PSCM2 - Page 5

65mm
5.5mm
A1
A2
STEP 2A Wood Stud Option
WARNING:
Avoid potential personal injuries and property damage!
●
Anything covering the ceiling must not exceed 5/8 in. (16 mm)
● Nominal wood stud size: common 2 x 4 in. (51 x 102 mm) minimum
1½ x 3½ in. (38 x 89 mm)
● Stud center must be verified
4
[5]
[2]
7/32 in.(5.5mm)
Wood Drill
[7]
