Perlesmith PSCM2 - Installation Steps; STEP 1 Attach the U bracket [2] to Tube [5]; STEP 2 Attach U Bracket [2] to the Ceiling; STEP 2 A Wood Stud Option

STEP1
STEP 2A Wood Stud Option
WARNING:
WARNING:
Ensure the U Bracket [2] is securely fastened to the Ceiling
before continuing on to the next step.
Avoid potential personal injury or property damage! All lag
bolts [A1] MUST BE firmly tightened to prevent unwanted
movement of the
U Bracket [2] .
X
STEP 2 Attach U Bracket [2] to the Ceiling
For wood stud installation, follow STEP 2A
For concrete installation, follow STEP 2B
3
Attach the U bracket [2] to Tube [5]
a
b
a
b
c
e
g
B1
[5]
[2]
