Supplied Parts List
Wire Clip
1
TV Plate
(x1)
1
Support Pillar Tempered Glass Monitor Bracket
Plastic Socket
(x1)
2
(x1)
3 4
(x2) (x1)
5
M8x35 Bolt M6x60 Bolt
(x3)
A
(x4)
B
M8X22X2
(x3)
C
M8X22X2
(x3)
D
Metal Pad
Safety Lock
Rubber Pad
(x2)
E
(x6)
F
(x2)
G
(x1)
H
(x1)
I
(x4)
J
M6x16 Bolt M6x30 Bolt M8x16 Bolt
(x4) (x4)
(x4)
TV4TV2
M6x50 Bolt
(x4)
TV3TV1
M8x45 Bolt
(x4)
TV5
M8x65 Bolt
(x4)
TV6
SP1 SP2
(x8)
TV7
(x8)
TV8
Spacer with 3 holes
(x4)
TV9
Allen Key Allen Key
Steel Washer
Plastic Washer
WARNING! SEVERE PERSONAL INJURY AND PROPERTY DAMAGE
CAN RESULT FROM IMPROPER INSTALLATION OR ASSEMBLY.
READ FOLLOWING WARNINGS BEFORE BEGINNING.
•If you do not understand the instructions or have any concerns or questions,
please contact customer service at supportus@perlesmith.com
•Do not install or assemble if the product or hardware is damaged or missing.
•Not all parts and hardware included will be used. lf you require replacement
parts, contact customer service at supportus@perlesmith.com
•This product may contain moving parts. Use with caution.
•Please check www.perlesmith.com for more products and company
information.
