Perlesmith PSMFK1 - Step 5: Adjustments; Level Adjustment; Tilt Adjustment

11
Level your TV
If needed, the TV can be levelled.
Loosen the bolt [S1] Tighten the bolt [S1]
to secure TV in place
3/8 in.(10mm)
Socket Wrench
1
2
3
1. Loosen four preassembled nuts.
2. Adjust the TV to the desired tilting angle.
3. Fasten the nuts to hold the tilting angle of the TV.
Fasten the nuts
S1
S1
5-2 Tilt Adjustment
Step 5 Adjustments
5-1 Level Adjustment
Adjust the tilting angle
Loosen the nuts
