Design and Function
25
Owner’s Manual Corpus
WARNING
Do not put weight on the backrest while adjusting the angle.There is a risk of pinching accidents.
Design and function
Manual Seat Functions - Backrest Recline
The tilt angle of the backrest can be regulated by an adjustable clamp tube with
instant locks in a number of fixed positions. From an upright position the back-
rest can be tilted to a maximum angle of 135° backwards.
1. Pull out the spring-loaded handle of the instant lock so that the clamp tube
runs freely and it is possible to adjust the angle of the backrest.
2. Set the backrest at the desired angle and then lock it in position by
releasing the handle and allowing it to engage in the selected hole in the
clamp tube.
3. Check after adjusting the backrest that it is locked in position.
