Transport
34
Owner’s Manual Corpus
Transport
In order to make transporting the wheelchair or seat easier, the backrest can be
removed in a few simple steps.
Corpus Seat, Standard
(Fixed Back or Manual Recline)
1. Remove the back cushion.
2. Loosen the locking peg and the locking knobs on the back of the backrest.
3. Push the upper part of the back support slightly forward to release it from
the locking peg and lift the backrest upwards to remove it.
If necessary, the headrest can also be detached, see page 30-31.
Locking peg
Locking knobs
Release the Locking Peg and Knobs.
