Settings and adjustments
32
Owner’s Manual Corpus
Settings and adjustment
Control Panel, Swivelling Mounts
The position of the control panel can be adjusted lengthways into the optimum
operating position. It is also possible to turn the panel sideways to facilitate get-
ting in and out of the wheelchair.
Length Adjustment
1. Loosen the screw on the panel mount and adjust the position of the panel
as required.
2. Tighten the screw.
Angle Adjustment by means of the Friction Joint.
By means of the friction joint it is possible to adjust how much force is required
to swivel the panel out sideways.
Screw
Handle
Friction Joint Handle.Length Adjustment Screw.
