Settings and adjustments
31
Owner’s Manual Corpus
Head rest with wide adjustment
capability.
Head rest adjustment.
Settings and adjustment
Head rest (accessory)
This head rest has extended adjustment
capability to give the user the best com-
fort. The head rest is easy to
remove/remount while preserving the
same settings.
Removal
1. Release the knob (3) on the rear of
the back rest, see photo.
2. Detach the head rest by lifting it
straight up.
Mounting
Mount in reverse order.
Adjustment of height/depth
1. Release the knob (1) on the rear of
the back rest, see photo.
2. Adjust head rest height/depth as
required.
3. Tighten the knob (1).
Adjustment of angle
1. Release the knob (2) on the rear of
the head rest, see photo.
2. Adjust head rest angle as required.
3. Tighten the knob (2).
2
3
1

WARNING
Do not put weight on the headrest while adjusting it.
