Permobil Hälsa Bed Owner’s Manual 2 – Assemble the frame
www.permobil.ca 11
8 - Lift the head and foot decks so that you can align the locking inserts on the foot deck to
the locking slots on the head deck.
9 - Ensure that each locking insert is fully in the corresponding locking slot.
10 - Rotate the red knobs clockwise to lock the decks together.
11 - Ensure that the decks are securely locked together.
INSERT INTO
TURN THE RED KNOB
