Permobil Hälsa Bed Owner’s Manual 2 – Assemble the frame
www.permobil.ca 8
2 – Assemble the frame
The Hälsa Bed frame is provided in 4 pieces. You will lie the head and foot supports on the floor
and then attach the head frame assembly to the head support and the foot frame assembly to the
foot support. Casters come installed on the frame.
STEPS
1 - Lock casters as necessary.
2 - Lie the head and foot supports down about 91 cm (3') apart.
PUSH DOWN TO
LOCK CASTER
NOTE THE
LOCATION OF
SLOTS ON HEAD
SUPPORT
NOTE THE
LOCATION OF
SLOTS ON FOOT
SUPPORT
SUPPORT
HEAD
SUPPORT
FOOT
SUPPORT
