-50-
Charging fuse
The charging fuse is next to the main circuit-breaker, see fig. 37.
NB! The wheelchair should be inoperative when you change the charging
fuse.
Owner´s manual Koala Repairs
Fig.47. Main circuit-breaker and
charging fuse
Main circuit-
breaker
63A
Charging fuse
15A
Repairs
Resetting the main fuse/battery cut-out
The main fuse also functions as a battery cut-out but is still referred to as the
main fuse in the user instruction.
NB! First switch off the power on the maneuvering panel before switching the
power off at the circuit breaker.
Main circuit breaker
You don’t normally need to change the main fuse, as you can reset it when it
trips. You reset it by switching it to the "ON" position. The main fuse is under
the chassis, over the right, rear wheel, see fig. 37.
NB! If the circuit breaker trips, it usually means that there is a serious electrical fault.
Before you reset the main fuse, check carefully or, call a qualified service technician.
