Permobil Koala - Seat Control Panel

-34-
Owner´s manual Koala Design and Function
1. Seat lift
2. No function
3. No function
4. No function
Fig. 20. Seat control panel
1234
Seat control panel
The seat control panel is attached to the right or left-hand armrest behind the
control panel. The picture below show the function of the seat control panel.
Seat lift, fig. 20:1
The seat is raised when the top part of
the seat lift button is pressed, and
lowered when the bottom part of the
button is pressed.
