PART 8: MAINTENANCE AND SERVICE
PB1319 (CAT. NO. 5296 ) —109— 22-01691 (R02/02)
Fuel &
Tanks
Fuel tank breathers Check for proper function; clean the drain hoses. X
Fuel tank straps Check the strap tightness; tighten to proper torque value as required:
-Aluminum tank: 30 Lb. ft. (41 N.m.)
-Cylindrical Steel tank: 8 Lb. ft. (11 N.m.)
XX
Fuel tank steps Check for snug fit of side plates against tank and tank straps.
Check for damaged or broken steps, missing bolts, and missing
grommet between tank and side plate. Replace missing or dam-
aged parts and adjust for fit as required.
X
Driveshafts Models 1610-1810 & SPL-
90 slip member & U-joints
Lubricate. X X
Model SPL-100 slip mem-
ber & U-joints
Lubricate. X
Models SPL-140/140HD/
170/170HD/250/250HD
slip members & U-joints
Lubricate. X
Models SPL-140XL/
170XL/250XL slip mem-
bers and U-joints (ON
HIGHWAY & LINE HAUL)
Lubricate. 360,000 miles/
576,000 km/
every 3 years
SYSTEM COMPONENT MAINTENANCE TASK
Recommended
PM Interval
I ABCDE
