1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
02972A
20
PART 4: CONTROLS AND DISPLAYS YOUR INSTRUMENT PANEL
(R10/06) Y53-6007 – 17 –
RIGHT SIDE
1. Parking Brake Valve 12. Engine Brake
2. Trailer Air Supply Valve 13. Engine Brake
3. Heater/AC Control Panel 14. Load Lights Switch
4. Fog Lights Switch 15. Interaxle Differential Lock
Switch
5. Engine Fan Switch 16. 5th Wheel Lock Switch
6. ID/Clearance Lamps Flash 17. Air Suspension Switch
Switch
7. Trailer Brake Lever 18. Radio
8. Cruise Control Switch 19. CB Radio
9. Transmission Temperature 20. Selected Option Switch
10. Cruise Control Switch 21. Mirror Heater Switch
11. Pyrometer
