DASH-MOUNTED FEATURES PART 4: CONTROLS AND DISPLAYS
– 26 – Y53-6007 (R10/06)
Dome Light Switch
02894A
I
O
A momentary switch controls the main dome light:
OFF (O) Position: Light is off.
ON (I) Position:
Press once: Light will turn on at high intensity.
Press again: Light will shift to low intensity.
Press a third time: Light will turn off.
Windshield Wipers and Washers
02896
Wiper
To turn on the wipers rotate the knob to the right. As the
knob is rotated, the speed of the wipers increases. To turn
off the wipers, rotate the knob to the left.
Washer
To use the washer, push the knob showing the symbol
above. With the electric wipers, the wipers will come on for
a short time when the washer starts.
