TIGHTENING TORQUES
9
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
TIGHTENING TORQUES
 Body panels.
 Cycle part.
 Standard.
Front mudguard. 0.8 m.daN.
Handlebar cover. 0.1 m.daN.
Front shield panels. 0.1 m.daN.
Rear shield. 0.4 m.daN.
Footboard. 1 m.daN.
Rear panels. 0.1 m.daN.
Grab handle. 2 m.daN.
Rear mudguard. 0.8 m.daN.
Front wheel spindle. 6 m.daN.
Rear wheel spindle nut. 10 m.daN.
Linkrod to engine pivot. 5.2 m.daN.
Linkrod to frame pivot. 5.2 m.daN.
Shock absorber top mount. 4.31 m.daN.
Shock absorber bottom mount. 2 m.daN.
Exhaust to cylinder mounting nut. 1.5 m.daN.
Exhaust to casing mounting bolt. 2 m.daN.
Upper cone (in 2 operations). 4/2.3 m.daN.
Upper cone locknut. Hand tightened.
Steering locknut. 7 m.daN.
Front brake caliper. 2.5 m.daN.
Front brake disc. 1 m.daN.
Handle bar. 2.5 m.daN.
Nut and bolt 5 mm diameter. 0.5 m.daN.
Nut and bolt 6 mm diameter. 1 m.daN.
Nut and bolt 8 mm diameter. 2.2 m.daN.
Nut and bolt 10 mm diameter. 3.5 m.daN.
Nut and bolt 12 mm diameter. 5.5 m.daN.
