BODY PANELS
16
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
- Fit the locating pin (1) into the holes provided
in the under body panel.
Follow the procedure to install the footboard carefully in order to avoid it from contacting the
radiators.

Installing the front lower shield panel.
- Install the shield panel by fitting the footboard
locating pins (1) into the holes provided in the
under shield panel.
1
1
