Pfaff 1163

Adjustment
13 - 8
13.04.07 Knee lever stop
Requirement
When knee lever 3 has been moved as far as possible, the presser foot should rise
approx. 9 mm above the needle plate.
● Adjust screw 1 (nut 2) in accordance with the requirement.
103-009
0
Fig. 13 - 07
76-033
1
2
3
76-053
9 mm
