Preparation
9.08 Selecting the stitch length
● Turn the machine on.
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
Fig. 9 - 08
If the display shown in Fig. 9-08 does not appear:
● Select the function select program.
● Enter program number 0.
● Confirm with the Enter key.
● Select the function stitch length with number key 0.
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
Fig. 9 - 09
● Using the number keys, enter the desired stitch lengths.
The value entered will be assumed for both the feed wheel and the roller-
presser.
If the values for the feed wheel and the roller-presser are to vary, the feed
wheel and the roller-presser must be selected individually.
When entering varying feeds:
● Select the feed wheel or roller-presser separately using the arrow keys (observe cursor).
● Enter the required value and confirm with the Enter key.
0
Enter
FEED WHEEL 2.5MM ROLLER-PRESSER: 2.5MM
(VALID: 0.8MM - 5.0MM DIFF.: 1MM)
Enter
9 - 7
