Pfaff 1526

11 - 17
Adjustment
58.039
Fig. 11 - 14
18 mm
1
2
11.04.14 Clearance between lifting presser and needle plate
Requirement
With the lifting presser raised there must be a clearance of approx. 16 mm between lifting
presser and needle plate.
● Raise the lifting presser and lock it with fixing key 1.
● Turn plunger 1 (nut 2) according to Requirement.
