PFAFF 5
Purpose of application
PFAFF 3822-1/22
Integrated sewing unit for run-stitching and edge trimming.
PFAFF 3822-1/24
Integrated sewing unit for run-stitching and feathered edge trimming.
1 Specifications of the PFAFF 3822-1/22
PFAFF 3822-1/24
Sewing machine head : for -1/22
487-706/81-731/12-900/51-911/15-910/05-917/.. BSx5
for-1/24
487-706/81-731/12-900/51-911/15-910/05-917.. BSx3,5x6,5
Stitch type : 301
Maximum sewing speed : for -1/22 4000 s.p.m
for -1/24 3000 s.p.m
Maximum stitch length : for -1/22 5 mm
for -1/24 6,5x3,5 mm
Needle system : 134 KK
Needle size : 80
Trimming margin : 5,0 mm on PFAFF 3822-1/22
6,5 x 3,5 mm on PFAFF 3822-1/24
Fabric clearance : 7 mm
Sewing motor : for -1/22 Quick digital QD 552 P40 K2
for -1/24 Quick digital QE 5542 Q40 SE
Power input : 1,2 kW
Connection voltage : E 230 Volt, 50 / 60 Hz
Working pressure : 6 bar
Air consumption : ~40 standard litres
Workplace-related noise : at sewing speed n=2400 r.p.m: L
PA
≤ 75 dB(A)
Noise measurement according to DIN 45635-48-A-1.
Dimensions of unit : Length : 1365 mm
Breadth : 950 mm
Height : 1700 mm (with reel stand)
Weight : Net : 140 kg
Rights to modifications reserved Status: 02.94
