12 PFAFF
9 Inserting the needle
Needle system 134 KK
Switch off machine!
10 Winding the bobbin thread
.1 Place a bobbin on winder spindle 1 (Fig. 1).
.2 Press winder spindle 1 inwards
- Winder is engaged
.3 Thread up as shown in Fig. 2 and wind thread a few turns around bobbin.
.4 Bobbin is filled during sewing.
.5 To regulate the amount of thread: pin 2 (screw 3)
Note: If bobbin is wound unevenly, position thread guide 4 according (nut 5) and regulate
winding tension (chapter 11).
11 Regulating the winding thread tension
Knurled washer 6 (Fig. 2)
+= increase
- = decrease
