6 PFAFF
BI-02N
Pedal functions
0 = Neutral pedal position
+ = Pedal forwards
+1 = Presser foot down
+2 = Sewing (and when edge trimmer is
engaged: suction and sewing
- = Pedal backwards
-1 = Backtack and raise presser foot
-2 = Thread trim
Abb.004
Quick Digital motor
control panel (see
manufacturer’s
literature)
Twelve-key panel
2 Controls and indicators
General view
only with 3822-1/24
Knee switch for feathered edge trimmer
for enabling and disabling:
- Hook knife
- Blow impulse for ply separation
Mains switch
for switching on and off the
entire sewing unit
Knee switch for fullness
By operating the knee switch it is possible to switch
between the last gather amount that was inputted on the
twelfe-key keypad and sewing without fullness
